Anchor Highland Freestanding Wall

Product Description

Features & Benefits

The Anchor Highland Stone® system combines a rugged, textured exterior with the reliable and easy-to-install design characteristic of Anchor Retaining Wall Systems. Its stone-like, multi-colored face creates the appearance of a natural rock wall, adding a touch of authenticity and charm to any landscape. This system is engineered for structural integrity and simplicity, making it an excellent choice for both DIY enthusiasts and professional landscapers.

Dimensions
Large: 6″ x 18″ x 9″
Medium: 6″ x 12″ x 9″
Small: 6″ x 6″ x 9″

Coverage
Large: 0.75 sq. ft.
Medium: 0.50 sq. ft.
Small: 0.25 sq. ft.

Setback/System Batter: The blocks have a setback of 1 1/8 inches, resulting in a system batter of 10.6°
Construction: Made from a “no slump” concrete mix, the blocks are manufactured under extreme pressure and high-frequency vibrations, achieving a compressive strength greater than 3500 psi and a water absorption maximum of 7%
Installation: The system features the original rear-lip locator, facilitating faster and more reliable construction It can be used for gravity walls up to 4 feet 6 inches high, including the buried course but excluding the cap
Taller walls can be built using geosynthetic reinforcement or the Anchorplex™ retaining wall system when designed by a qualified engineer
Radius: Minimum outside radius (top course to the front of the units) is 4 feet, and minimum inside radius (base course to the front of the units) is 8 feet
